FTTH 1x32 fiber optic switch with rackmount

Name: FTTH 1x32 fiber optic switch with rackmount
Brand: GEZHI or OEM
Price: 1 USD

Buy cheap FTTH 1x32 fiber optic switch with rackmount product

Brand Name : GEZHI or OEM

Model Number : 1x32 Optical Switch

Certification : CE RoHS,ISO9001

Place of Origin : China

MOQ : 1pc

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100000Channel per month

Delivery Time : 5-8 work days

Packaging Details : Paper box

Wavelength : 1260-1650nm

Warranty : 3 Years

Control Type : Latching or Non-Latching

Port : 1x32

Voltage : 3V or 5V

Application : Cable Monitoring and Maintaining system

Contact Now

Product Package

FTTH 1x32 fiber optic switch with rackmount

Finished Item

Inner Package

Carton

Similar Products

FTTH 1x32 fiber optic switch with rackmount

1x2 optical switch

1x4T optical switch

1x1 optical switch

Product Overview

FTTH 1x32 fiber optic switch with rackmount

1x32 Desktop Optical Switches Rackmount

1×N rack-mounted optical switch is used for selecting and controlling optic path. It has an important role in the optical communication and applies to multipoint monitoring of optical transmission system, LAN light source/detector auto exchange and optical sensor monitoring system. It also can be used for optic fiber, optical passive components, optical network and cable testing.

Specifications

Parameter	Unit	OSW-1x32-U
Wavelength Range	nm	850±40/1300±40	1260～1650
Operating Wavelength	nm	850/1300	1310/1550
Insertion Loss	dB	Typ. ≤0.8dB, Max.≤1.5 dB	Typ. ≤0.8dB,Max.≤1.5 dB
Return Loss	dB	MM≥35 SM≥50
Crosstalk	dB	MM≥50 SM≥70
Polarization Dependent Loss	dB	0.05
WDL	dB	≤0.25
TDL	dB	≤0.25
Repeatability	dB	≤±0.02
Power Supply	V	AC:100～ 240 (50/60Hz)
Lifetime	times	≥107
Switch Time	ms	≤10
Optical Power	mW	≤500
Operating Temperature	℃	-10~+60
Storage Temperature	℃	-40~+85
Dimension	mm	1U:483 x 230 x 45

Features

Low insertion loss, Fast switching

SerialNet, High Reliability, High Stability

 			LED display panel. Visual display

 			Transparent transmission signal

RS232 Control & RJ45 Ethernet Remote Management
